Technical Specifications A - 7
MC65 Accessory Specifications
Single Slot USB Cradle
5 USB_D-
6 USB_D+
7 Ground
Table A-3
External Connector Pin-Outs (Continued)
Pin Description
Table A-4
Single Slot USB Cradle Technical Specifications
Feature Description
Dimensions Height: 7.1 cm (2.80 in.)
Width: 11.0 cm (4.33 in.)
Depth: 15.0 cm (5.91 in.)
Weight 210 g (7.41 oz)
Input Voltage 12 VDC
Power Consumption 30 watts
Interface USB
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
