Appendix A Technical Specifications
MC65 Technical Specifications
The following tables summarize the EDA’s intended operating environment and technical hardware specifications.
MC65
Table A-1
MC65 EDA Technical Specifications
Item Description
Physical Characteristics
Dimensions Height: 16.2 cm (6.38 in.)
Width: 7.7 cm (3.03 in.)
Depth: 3.4 cm (1.32 in.)
Weight 359 g (12.5 oz.)
Display Transflective color 3.5” VGA with backlight, TFT-LCD, 65K colors,
480 W x 640 L
Touch Panel Glass analog resistive touch
Backlight LED backlight
Battery Pack Rechargeable Lithium Ion 3.7V, 3600 mAh battery
Backup Battery Rechargeable Lithium-alloy 3.0 V, 2.5 mAh (not user accessible)
Expansion Slot microSD slot (supports up to 32 GB).
Connection Interface USB 2.0 High Speed (host and client)
Notification Audible tone plus multi-color LEDs
Keypad Options numeric, QWERTY, AZERTY or QWERTZ
Audio Dual microphone support with noise cancellation; vibrate alert; speaker;
Bluetooth headset
