A - 4 MC65 Integrator Guide
Wireless Wide Area Network GSM-HSDPA
Global:
3GPP TS 51.010, 3GPP TS 34.121, 3GPP TS 34.123, GCF and
PTCRB approved
USA:
FCC Part 22, Part 24
Canada:
RSS-132, RSS-133
EU:
EN 301 511, EN 301 908
Australia:
AS/ACIF S 024.1 & 3
CDMA-EvDO Rev A
USA:
FCC Part 22, Part 24
Canada:
RSS-132, RSS-133
RF Exposure
USA:
FCC Part 2, FCC OET Bulletin 65 Supplement C
Canada:
RSS-102
EU:
EN 50360, EN62311
Australia:
Radio communications Standard 2003
EMI/RFI
USA:
FCC Part 15, Class B
Canada:
ICES 003 Class B
EU:
EN55022 Class B, EN55024, EN 301 489-1, EN 301 489-3, EN 301 489-7,
EN 301 489-17, EN 301 489-24, EN 60601-1-2, EN 50121-3-2, EN 50121-4
Australia:
AS/NZS CISPR-22
Data Capture Specifications
Options 2D imager, 2D imager and color camera
2D Imager Engine (SE4600) Specifications
Field of View Horizontal - 39.6°
Vertical - 25.7°
Optical Resolution WVGA 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: SR - 7.5 in. (19 cm)
Aiming Element (VLD) 655 nm +/- 10 nm
Table A-1
MC65 EDA Technical Specifications (Continued)
Item Description
