Symbologies 12 - 75

Redundancy Level 4

The following code types must be successfully read three times before being decoded:

Table 12-5

Redundancy Level 4 Codes

Code Type Code Length

All All

*Redundancy Level 1

(01h)

Redundancy Level 2

(02h)

Redundancy Level 3

(03h)

Redundancy Level 4

(04h)
