2 - 2 Model Information & Accessories
Model Specifications
GENERAL RECEIVER TRANSMITTER
ETSi: ETS 300 394-1 Receiver Type: Direct
Conversion
Modulation Type:
π/4DQPSK
4-QAM
16-QAM
64-QAM
Type Number: Frequency Range: RF Power:
MTM5400/MTM800 FuG
ENH 380–430 MHz
MT912M MTM5400 /
MTM800 FuG
ENH
380–430 MHz TMO
DMO
MSPD
TEDS
10 W / 40 dBm
10 W / 40 dBm
5.6 W / 37.5 dBm
3 W / 35 dBm
Temperature Range for Transceiver: Channel Spacing: 25 kHz Frequency Range TMO:
Operating
Storage:
-30°C to +60°C
-40°C to +85°C Sensitivity (3.5%) BER: -114 dBm
MTM5400/MTM800 FuG
ENH
380–430 MHz
Power Supply:
Minimum:
Nominal:
Maximum:
Max. Current
10.8 Vdc
13.2 Vdc
15.6 Vdc
Approx. 3.5 A
Intermodulation:
Blocking (50–100 kHz):
-47 dBm
-40 dBm
Frequency Range DMO:
MTM5400/MTM800 FuG
ENH
380–430 MHz
Dimensions (HxWxD) in mm: Spurious Rejection: -45 dBm Frequency Stability:
Transceiver with
Enhanced Control Head,
Dash Mount 60 x 188 x 198
Adjacent Channel
Interference Ratio: -45 dB
Locked to Base
Not Locked to Base
+/-100 Hz
+/- 1 kHz
Weight in grams: Frequency Stability: Spurious Emissions:
Transceiver with
Enhanced Control Head,
Dash Mount 1500
Locked to Base
Unlocked to Base
+/-100 Hz
+/- 1 kHz
Conducted/Radiated - 36 dBm <=1 GHz
- 30 dBm > 1 GHz
Audio Rated (@4 Ohms):
For External Speaker:
Distortion at Rated Audio:
10 W
5% Max.
Adjacent Channel Power Ratio
(@ ± 25 kHz)
380–430 MHz -60 dBc
NOTE:
Technical information may be subject to change without further notice.
