Maintenance 6 - 35
Service Aids
The following table lists the service aids recommended for working on the terminal. While all of
these items are available from Motorola, most are standard workshop equipment items, and any
equivalent item capable of the same performance may be substituted for the item listed.
Table 6-4 Service Aids
Motorola Part No. Description Application
6666500A01 Housing Eliminator Test Fixture used to bench test the terminal
PCB
6686119B01 Dismantling Tool Assists in the removal of terminal Enhanced
Control Head
0180320B16
6680321B81
6680321B56
Torx Screw Driver Kit (T6,8,10,15,25)
Torx Bi t
Insert Bit extra long
–
T-20 TORX
(or equivalent)
Screwdriver with torque meter –
–
–
5/16” socket driver
Phillips screwdriver
To assemble & disassemble GPS nut
To assemble & disassemble SIM dust cover
plate
