6 - 34 Maintenance
Figure 6-49 Cradle Back Housing Assembly Installation 1
Figure 6-50 Cradle Back Housing Assembly Installation 2
20. Latch the Handset back on the Cradle as shown in Figure 6-51 below.
Figure 6-51 Handset Assembly
ZWG0130215-O
Main screws
ZWG0130215-O
ZWG0130215-O
