Name: Motorola Symbol LS4278
Brand: Motorola
Rating: 5 (1 reviews)

To Next Page

To Previous Page

Keyboard Wedge Interface 6-7

Keyboard Wedge Country Types (Country Codes)

Scan the bar code corresponding to the keyboard type. If the keyboard type is not listed, see Alternate Numeric Keypad Emulation on

page 6-10.

*North American

German Windows

French Windows

French Canadian Windows 95/98

French Canadian Windows XP/2000

Spanish Windows

Italian Windows

Default Chapter5
