Symbol LS4278 Product Reference Guide14-10

Criteria

Code Types

Select any number of code types to be affected. All selected codes must be scanned in succession, prior to selecting other criteria. If

a code type is not selected, all code types are affected.

Scan the bar codes for all code types desired before selecting other criteria.

Code 39

Codabar

GS1 DataBar-14

GS1 DataBar Limited

GS1 DataBar Expanded

Code 128

Default Chapter5
