Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
Port Event Settings
Port Events are related to the activity of a specif ic port.
Warning e-mail is sent when…
The port is connected to another device.
Link-OFF
The port is disconnected (e.g., the cable is pulled out, or the opposing device
shuts down).
Traffic-Overload
The port’s traffic surpasses the Traffic-Threshold f or that port (provided this item
is Enabled).
Enter a nonzero number if the port’s Traf f ic-Overload item is Enabled.
Traffic-Duration (sec.)
A Traffic-Overload warning is sent every Traf f ic-Duration seconds if the average
Traffic-Threshold is surpassed during that time period.
Four response actions are available on the EDS E series when events are triggered.
The EDS E series will send a notification to the trap server when an event is triggered.
The EDS E series will send a notif ication to the email server def ined in the Email Setting.
The EDS E series will record a syslog to syslog server defined in Syslog Server Setting.
Relay
The EDS E series supports digital inputs to integrate sensors. When an event is triggered,
the device will automate alarms through the relay output.
Severity
Severity Description
Emergency System is unusable
Alert Action must be taken immediately
Error Error conditions
Warning Warning conditions
Notice Normal but signif icant condition
Inf ormation Informational messages
Debug Debug-level messages
NOTE
The Traf f ic-Overload, Traf f ic-Threshold (%), and Traf f ic-Duration (sec.) Port Event items are related. If you
Enable the Traf f ic-Overload event, then be sure to enter a nonzero Traffic-Threshold percentage, as well as
a Traffic-Duration between 1 and 300 seconds.
