Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
Select the ingress rate limit for different packet types from the
f ollowing options: Unlimited, 128K, 256K, 512K, 1M, 2M, 4M,
8M
Limit Broadcast 8M
Limit Broadcast,
Multicast, Flooded
Limit Broadcast,
Multicast
Egress Rate Limit
Egress rate (% of max.
throughput)
Select the egress rate limit (% of max. throughput) f or all
packets f rom the f ollowing options: Not Limited, 3%, 5%,
10%, 15%, 25%, 35%, 50%, 65%, 85%
Unlimited
Rate Limiting: Port Disable
Port disable duration
(1-65535 seconds)
When the ingress multicast and broadcast packets exceed the
ingress rate limit, the port will be disabled f or this period of
time. During this time, all packets f rom this port will be
discarded.
30 seconds
Ingress (f rames per
second)
Select the ingress rate (f ps) limit f or all packets f rom the
f ollowing options: Not Limited, 4464, 7441, 14881, 22322,
Unlimited
NOTE
The Rate Limiting function is f or broadcast packets only.
