Moxa Technologies ioLogik E1210 User Manual

B
B. EtherNet/IP Default Address Mappings
ioLogik E1200 EtherNet/IP Map
Supported Service
Service Code Class Level Instance Level Service Name Description
0x05 No Yes Reset Restart device
0x0E Yes Yes Get_Attribute_Single Read an attribute
0x10 No Yes Set_Attribute_Single Modify an attribute
Assembly Object (0x04)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT Revision of this object
0x65 0x03 GET Input Data ARRAY of BYTE Data Map by Models
0x65 0x04 GET Size UINT Number of BYTE in attribute
0x03
0x66 0x03 SET Output Data ARRAY of BYTE Data Map by Models
0x66 0x04 GET Size UINT Number of BYTE in attribute
0x03
Input Data Map by Models
Model Channels BYTE # Access Name Data
Type
Description
ioLogik
E1210
DI-15…00 1…0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
65…2 GET diCounterValu
e
UDINT DI - Counter mode - value
ioLogik
E1211
DO-15…00 1…0 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1212
DI-15…00 1…0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
65…2 GET diCounterValu
e
UDINT DI - Counter mode - value
DO-07…00 66 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1213
DI-11…00 1…0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
49…2 GET diCounterValu
e
UDINT DI - Counter mode - value
DO-07…00 50 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1214
DI-05…00 0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
24…1 GET diCounterValu
e
UDINT DI - Counter mode - value
RLY-05…00 25 GET relayStatus BOOL Relay - Relay mode - status (0: OFF, 1:
ON)
ioLogik
E1240
AI-07…00 15…0 GET aiValueRaw UINT AI - raw value
ioLogik
E1241
AO-03…00 7…0 GET aoValueRaw UINT AO - raw value

Moxa Technologies ioLogik E1210 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	671345 h
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.11 A
AC input voltage	24 V
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC Part 15 Subpart B Class A, IEC 61000-4, IEC 61000-6
Product color	Silver

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
