Moxa Technologies ioLogik E1210 User Manual

D
D. Network Port Numbers
ioLogik E1200 Network Port Usage
Port Type Usage
68 UDP BOOTP/DHCP
69 UDP Export/import configuration file
80 TCP Web console service
161 UDP SNMP Agent
502 TCP Modbus/TCP communication
2222 UDP EtherNet/IP implicit message
4800 UDP Auto search
9020 TCP Peer-to-peer (default)
10124 TCP Configuration port (ioSearch)
44818 TCP EtherNet/IP explicit message

Moxa Technologies ioLogik E1210 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	671345 h
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.11 A
AC input voltage	24 V
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC Part 15 Subpart B Class A, IEC 61000-4, IEC 61000-6
Product color	Silver

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
