Moxa Technologies ioLogik E1210 User Manual

5
5. Activation Process for the EtherNet/IP
Function
The ioLogik E1200 series supports the EtherNet/IP protocol once the device has been registered and activated.
In this note, we will explain how to activate the EtherNet/IP function in the ioLogik E1200 series. The
EtherNet/IP function can only be activated after the following firmware and utility versions are up-to-date.
• ioLogik E1210 V2.5 (std. version)
• ioLogik E1211 V2.4 (std. version)
• ioLogik E1212 V2.5 (std. version)
• ioLogik E1213 V2.6 (std. version)
• ioLogik E1214 V2.5 (std. version)
• ioLogik E1240 V2.4 (std. version)
• ioLogik E1241 V2.5 (std. version)
• ioLogik E1242 V2.5 (std. version)
• ioLogik E1260 V2.5 (std. version)
• ioLogik E1262 V2.5 (std. version)
• ioSearch V1.15 (std. version)
Take the following steps to activate the EtherNet/IP function:
Step 1: Assign the license file folder
After installing ioSearch V1.15, the user should assign a folder to place the license file in.
Click
System

Options
to find the window displayed below. Next, click the settings icon
(shown at
the right) to assign the license folder. Click OK to complete the settings.
Settings Icon

Moxa Technologies ioLogik E1210 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	671345 h
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.11 A
AC input voltage	24 V
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC Part 15 Subpart B Class A, IEC 61000-4, IEC 61000-6
Product color	Silver

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
