Moxa Technologies ioLogik E1210 User Manual

ioLogik E1200 Series Using the Web Console
3-19
Sample Peer-to-Peer Configuration
The following is an example of configuring DO (Server IP: 192.168.127.253) to DI (Client IP: 192.168.127.252)
peer-to-peer functionality with two ioLogik E1200 devices.
Server Settings:
Client Settings:
NOTE
Refer to the table below for maximum number of rules supported at different signal frequencies.
1 Hz 2 Hz 4 Hz 10 Hz 20 Hz
1 rule
    
10 rules
  
20 rules
  
30 rules
 
40 rules
 
50 rules


Moxa Technologies ioLogik E1210 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	671345 h
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.11 A
AC input voltage	24 V
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC Part 15 Subpart B Class A, IEC 61000-4, IEC 61000-6
Product color	Silver

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
