Moxa Technologies ioLogik E1210 User Manual

ioLogik E1200 Series Using the Web Console
3-9
NOTE
The Host Connection Watchdog is disabled by default and must be enabled for Safe Status settings to take
effect.
Save Status On Power Failure: The ioLogik E1200 will automatically save the counter value when there is a
power failure if this function selected.
Reset Counter: Select this function to reset the counter.
The DI channel’s Alias Name and logic definition can also be configured on this page. You can apply the alias
name to all channels by selecting the Apply to all DI channels checkbox.
DI Channel Specification:

Moxa Technologies ioLogik E1210 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	671345 h
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.11 A
AC input voltage	24 V
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC Part 15 Subpart B Class A, IEC 61000-4, IEC 61000-6
Product color	Silver

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
