ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-2
NOTE
The Modbus/TCP ID of the ioLogik E1200 is set to “1” by default.
ioLogik E1210 Modbus Address and Register
Map
I/O
Parameter Name Description Start
Address
(decimal)
Function
Code
Start
Register
(decimal)
Length Access Type
DI_counterOverflowFl
ag
0: Normal, 1:
Overflow
1000 02:INPUT
STATUS
11001 16 R/W bit
DI_counterOverflowFl
agClear
1: clear
overflow flag
0288 01:COIL
STATUS
00289 16 R/W bit
DI_counterReset 1: reset to
initial value
0272 01:COIL
STATUS
00273 16 R/W bit
DI_counterStatus 0: STOP, 1:
START
0256 01:COIL
STATUS
00257 16 R/W bit
DI_counterValue high/low word 0016 04:INPUT
REGISTER
30017 32 R 2 words
DI_status 0: OFF, 1: ON 0000 02:INPUT
STATUS
10001 16 R bit
DI-all_statusFromDI-
00
0: OFF, 1: ON 0048 04:INPUT
REGISTER
30049 1 R word
System
Parameter Name Description Start
Address
(decimal)
Function
Code
Start
Register
(decimal)
Length Access Type
deviceName Each byte
represents
ASCII code of
each character
5040 04:INPUT
REGISTER
305041 30 R word
deviceUpTime unit: sec(s) 5020 04:INPUT
REGISTER
35021 2 R word
firmwareVersion e.g. V1.2.3 ->
1st byte: 1,
2nd byte: 2,
3rd byte: 3
5029 04:INPUT
REGISTER
35030 2 R word
firmwareBuildDate e.g.
Build1605171
8 -->
16051718
5031 04:INPUT
REGISTER
35032 2 R word
lanIp e.g.
192.168.127.
254 -> 1st
byte: 192, 2nd
byte: 168, 3rd
byte: 127, 4th
byte: 254
5027 04:INPUT
REGISTER
35028 2 R word
