Port Setting
Enable
Setting Description Factory Default
Checked Allows data and power transmission through the port Enable
Unchecked Immediately shuts off port access Enable
Power Limit
Setting Description Factory Default
Auto The amount of power assigned is determined according to the
class that is read from the powered device.
Auto
Manual The user can set the power limit value that indicates the
maximum amount of power available to the port.
Auto
The PoE Ethernet switch can monitor PD working status via its IP conditions. If the PD fails, the switch will not
receive a PD response after the defined period, and the authentication process is restarted. This is an excellent
function to ensure your network reliability and reduce management burden.
PD Failure Check
Setting Description Factory Default
Checked Enables the PD Failure Check function. Auto
Unchecked Disables the PD Failure Check function. Auto
IP
Setting Description Factory Default
Max. 15 Characters Enter the IP for the PD None
Period
Setting Description Factory Default
Max. 5 Characters Enter the time span for IP checking period None
PoE Timetabling
Powered devices usually do not need to be running 24 hours a
day, 7days a week. The PoE Ethernet switch provides a PoE
timetabling mechanism to let users set a flexible working
schedule for each PoE port to economize the system’s power
burden.
Port
Setting Description Factory Default
Port Enable a dedicated port Port 1
Enable
Setting Description Factory Default
Checked Enables the port for a defined time period Disable
Unchecked Disables the port for a defined time period
Weekly Timetabling
Day
Setting Description Factory Default
To Next Page
