Moxa Managed Ethernet Switch/Extender Featured Functions
3-41
CoS Mapping
CoS Value and Priority Queues
Setting Description Factory Default
Low/Normal/
Medium/High
Maps different CoS values to 4 different egress queues. 0: Low
1: Low
2: Normal
3: Normal
4: Medium
5: Medium
6: High
7: High
TOS/DiffServ Mapping
ToS (DSCP) Value and Priority Queues
Setting
Description
Factory Default
Low/Normal/
Medium/High
Maps different TOS values to 4 different egress queues. 1 to 16: Low
17 to 32: Normal
33 to 48: Medium
49 to 64: High
