MP Systems R Series - Mechanical Specifications

8 MPSYSTEMS-M-001/06
Control Power Control Signals Alarm Circuit
150VAC Transformer 24VDC NC
110VAC Secondary NO
Primary Fused
4.2. Mechanical Specifications
5. MODEL
LENGTH
(in)
WIDTH
(in)
HEIGHT
(in)
CAPACITY
(gal)
WEIGHT
(lbs)
VR8
36 28 42 50 800
RF8
RA11
36 28 42 50 900
VR16
42 38 42 70 1250
VRT
RF16
RT
VR20
42 38 42 70 1315
VRT40
52 49 53 80 2000
RT40
Accessories
RC36
39 26 23 N/A 450
MP1200
24 25 40 N/A 400
*Approximate values. All mechanical specifications are subject to change.
MODEL OUTPUT PRESSURE
VARIABLE
PRESSURE
FLOW RATE
Motor 1 Motor 2
VR8
250-1000 PSI 8 GPM N/A
RF8
250-1000 PSI 8 GPM N/A
RA11 (Adaptive Flow Rate)
250-1000 PSI
8 GPM 3 GPM
3,8 or 11 GPM Total
VR16
250-1000 PSI
16 GPM Total
VRT
8 GPM 8 GPM
RF16
250-1000 PSI
16 GPM Total
RT
8 GPM 8 GPM
VR10
500-3000 PSI 10 GPM N/A
VR20
250-1000 PSI 20 GPM N/A
VRT40
250-1500 PSI 20 GPM 20 GPM
RT40
250-1500 PSI 20 GPM 20 GPM
