24 MPSYSTEMS-M-001/06
6.5. High Pressure Installation
Caution: Please refer to Section 11: Hose Identification to properly identify hoses and
fittings or contact machine tool manufacture. Hoses must be rated for proper pressure. If
properly rated hoses are not present in machine tool, replacement hoses will be needed.
Coolant distributors present in machine tool MUST be able to withstand the pressure
created by unit. If coolant distributors are inadequate, they will need to be modified. If
unsure contact MP SYSTEMS (877-689-1860).
6.5.1. Generic Mill Installation
1. Disconnect hose from machine tool through spindle pump;
Through spindle pump, typically mounted to plate that covers machine tool tank.
2. Use supplied JIC to JIS adapter(s) to connect supplied high pressure hose to machine tool
high pressure hose;
Installation kit ships with all necessary adapters for installation.
Warning: Ensure high pressure hose(s) DO NOT rub on any hard edge of machine tool.
Rubbing hose(s) can cause unnecessary wear which can lead to hose rupture.
