MP Systems R Series - Power Harness Installation

17 MPSYSTEMS-M-001/06
6.3.2. Power Harness Installation
1. Mount supplied power harness with hardware provided in installation kit and route cable:
 Make sure R Series power cable is able to reach mounted power harness.
 If 3/4” conduit plug is not available, knock out hole and use supplied cord grip.
2. Wire power cable in parallel with machine tool power:
 Be sure to leave enough cable to properly earth the unit.
3. Locate proper earthing point. Attach using supplied ring terminals.
3 phase power installation should be performed by qualified personnel.
Circuit breaker kits are available in a wide range of capacities.
MODEL / TYPE Part #
R/VR Series - 208/230VAC AK CB40 KIT
w/ RC36 AK CB50 KIT
R/VR Series - 460VAC AK CB20 KIT
w/ RC36 AK CB40 KIT
RF16/RT/VR16/VRT Series - 208/230VAC AK CB70 KIT
RF16/RT/VR16/VRT Series - 460VAC AK CB40 KIT
Please refer to machine FLA to ensure proper circuit breaker kit is used.
