MP Systems R Series - Generic Mill Applications Wiring; Generic Lathe Applications Wiring

21 MPSYSTEMS-M-001/06
6.3.3.2. Generic Mill Applications
 Typical Mill installations require 1 port and 1 alarm signal.
 Locate TSP (Through Spindle) contactor in machine tool cabinet.
o Refer to machine tool electrical drawings booklet.
 Remove 3 phase power from bottom of low pressure TSP contactor.
 Some machine tools require the removal of secondary TSP 3 phase power.
 Wire ‘Normally Closed’ connections in SERIES with TSP overload circuit.
 Wire ‘Normally Open’ connections in PARALLEL with TSP overload circuit.
 Additional machine tool alarms may need to ‘jumped out’.
o Refer to machine tool electrical drawings booklet.
6.3.3.3. Generic Lathe Applications
 Typical lathe configurations consist of wiring control signals in SERIES with existing low
pressure contactor along with an external M-Code. This allows for both machine tool low
pressure and high pressure pumps to be utilized.
 Wiring control signals through machine tool low pressure contactor before M-Codes will ensure
the unit shuts down when machine tool goes into a hard alarm.
 Wire ‘Normally Closed’ connections in SERIES with machine tool low pressure coolant
overload circuit contactor.
 Wire ‘Normally Open’ connections in PARALLEL with machine tool low pressure coolant
overload circuit contactor.
 Additional machine tool alarms may need to be ‘jumped out’.
o Refer to machine tool electrical drawings booklet.
 Machine tool parameters may need to be set in order to latch external M-Code functions.
