14 Appendix
Messko GmbH 2020 101BA4001150/10 EN MSENSE
®
DGA 2/3
Seq.
No.
Art. No. Designation
10 1001101000 MSENSE® 2/3 ball valve DN80 PN16/285
For measuring pipe length 285 mm
Flange diameter: DN80
Pressure rating: PN16
Material: stainless steel V4A
Including O-ring gasket, material: FPM (Viton)
11 1001101100 MSENSE® 2/3 ball valve DN80 PN16/507
For measuring pipe length 507 mm
Flange diameter: DN80
Pressure rating: PN16
Material: stainless steel V4A
Including O-ring gasket, material: FPM (Viton)
12 1000341800 MSENSE® 2/3 flange gasket (flat) from ball valve
For flange diameter: DN50
Material: FPM (Viton)
13 1000627700 MSENSE® 2/3 flange gasket (O-ring) ID100x6 from ball
valve
For flange diameter: DN80
Material: FPM (Viton)
14 1001101200 MSENSE® 2/3 dummy plug for ball valve
Material: aluminum (offshore-resistant)
15 1001101300 MSENSE® 2/3 chain set 285
For measuring pipe length 285 mm (with chain connector)
Material: stainless steel V4A
16 1001101400 MSENSE® 2/3 chain set 507
For measuring pipe length 507 mm (with chain connector)
Material: stainless steel V4A
17 MS99105600 Tube of grease (Autol Top 2000) for offshore version
18 1000653603 MKaliba plug on USB plug (for devices built before 2016),
incl. USB cable
19 1001008300 MSENSE® service adapter (plug M12, 5-pole on USB,
length 3 m)
20 1000711400 MSENSE® Modbus connection plug M12, 5-pole (for self-as-
sembly)
21 1001853000 Y adapter (5-pole, for Modbus ring cabling)
22 1001403600 Y adapter (9-pole, for Modbus ring cabling, for devices built
in 2016)
Please contact Messko GmbH with questions regarding other flange ver-
sions and spare parts.
