14 Appendix
Messko GmbH 2020 95BA4001150/10 EN MSENSE
®
DGA 2/3
14.3 Connecting flange dimensions
Figure73: Flange DN50 PN6; DN50 PN16
1 For o-ring gasket (included in delivery)
2 For any gasket (not included in delivery)
Figure74: Flange DN80 PN16
1 For o-ring gasket (included in delivery)
2 For any gasket (not included in delivery)
