MR MSENSE DGA 2 - Spare Parts List

14 Appendix
Messko GmbH 2020100 BA4001150/10 ENMSENSE
®
DGA 2/3
14.6 Spare parts list
Seq.
No.
Art. No. Designation
1 1001099900 MSENSE® 2/3 oil extraction unit (standard)
Sample extraction adapter (standard version)
Material: stainless steel V2A and PTFE
2 1001100100 MSENSE® 2/3 oil extraction unit (offshore)
Sample extraction adapter (offshore version)
Material: stainless steel V4A and PTFE
3 1001100300 MSENSE® 2/3 USB stick
Including MESSKO® MSET parameterization software and
operating instructions
4 1001370400 MSENSE® 2/3 service adapter (standard)
With USB connection, length 3 m, 9-pole (for devices built in
2016)
5 1001382201 MSENSE® 2/3 plug (standard) 9-pole (for devices built in
2016; for self-assembly)
6 1001100500 MSENSE® 2/3 ball valve DN50 PN6/285
For measuring pipe length 285 mm
Flange diameter: DN50
Pressure rating: PN6
Material: stainless steel V4A
Including flat gasket, material: FPM (Viton)
7 1001100600 MSENSE® 2/3 ball valve DN50 PN6/507
For measuring pipe length 507 mm
Flange diameter: DN50
Pressure rating: PN6
Material: stainless steel V4A
Including flat gasket, material: FPM (Viton)
8 1001100700 MSENSE® 2/3 ball valve DN50 PN16/285
For measuring pipe length 285 mm
Flange diameter: DN50
Pressure rating: PN16
Material: stainless steel V4A
Including flat gasket, material: FPM (Viton)
9 1001100900 MSENSE® 2/3 ball valve DN50 PN16/507
For measuring pipe length 507 mm
Flange diameter: DN50
Pressure rating: PN16
Material: stainless steel V4A
Including flat gasket, material: FPM (Viton)
