11 Removal
Messko GmbH 202082 BA4001150/10 ENMSENSE
®
DGA 2/3
NOTICE
Danger of damaging the measuring pipe!
If the device is operated in front of a slide valve, the tightly tensioned chain
ensures that the measuring pipe of the device has been pulled out far
enough and that the slide valve does not collide with it when closing.
Figure61: Pulling the device out
4. Close any upstream valves and slides.
5. Close the ball valve and position the oil collecting tray under the opening
of the ball valve.
Figure62: Closing the ball valve
