13 Technical data
Messko GmbH 2020 91BA4001150/10 EN MSENSE
®
DGA 2/3
7
At the point of measurement
Device properties
Mechanical connection Via ball valve and configurable flange DN50 or DN80 (several flanges available);
with safety chain for safe installation and removal
Measuring pipe length Two different lengths for optimum measuring conditions;
Short measuring pipe: 285mm;
Long measuring pipe: 507mm
Oil extraction connection Luer lock socket on the device;
adapter set for safe and clean oil extraction included in the scope of delivery
Operation Optional VFD display (suitable for use in daylight) with three operating keys for
displaying measured values and messages as well as for calling up parameters
Materials used Stainless steel and aluminum;
All external parts and parts in contact with oil are weather resistant, resistant to
transformer oil and UV-resistant
Gasket material FPM (Viton®)
Available colors (terminal box) RAL7033
RAL7038
Degree of protection IP66
Dimensions 435 / 657 x 218 x 264mm (version with short / long measuring pipe)
Device weight Version with short measuring pipe: approx. 12kg
Version with long measuring pipe: approx. 14kg
(without ball valve / flange / safety chain)
Ball valve weight Approx. 6kg (including flange and safety chain)
Electrical connection
Voltage supply 95...280VAC, 50/60Hz or 95...280VDC (protected against polarity reversal)
Power consumption < 13W
Overvoltage category III
Connection terminals Voltage supply, relays and analog outputs: 2.5mm
2
, AWG14
Cable gland 3xM20x1.5 or 3x½“NPT; 8…15mm lead diameter
Interfaces
Relay outputs Four freely configurable signaling relays (one changeover contact each) for
warning and alarm messages and for maintenance messages from the device-
internal monitoring;
One signaling relay for safety messages (e.g. loss of voltage)
Contact current capacity:
250V AC / 5A; max. 400V AC, cos φ = 1 at 85°C;
30V DC / 5A to 300V DC / 0.25A
Analog outputs Passive, signal tolerance ±0.03mA, load resistance max.700Ω at 24VDC
MSENSE®DGA2: Two configurable outputs, 4...20mA
MSENSE®DGA3: Three configurable outputs, 4...20mA
Service interface 5-pole socket (Molex) for communication via Modbus RTU and parameterization
via MSET parameterization software
