NS50 wireless network switch
User Manual
Revision C
Chapter 5: Configuration Using the Web Interface
© 2012 MST Global
Commercial in Confidence
102
Switch Configuration
These settings control switch ports 1-8 and assign VLANs. The following settings are available for all
ports. Note that the x in each parameter is replaced by the relevant port number.
Field
Description
switch.port.x.enabled
0: Disabled
1: Enabled
switch.port.x.name
The name of the port
switch.port.x.vlan_mode
1: ACCESS_PORT
2: TRUNK_PORT
switch.port.x.vlan_membership
Bitmask of the VLAN ID of which the port is a member.
Additionally, ports 5-8 include the following:
Field
Description
switch.port.x.speed
1: 10 HALF
2: 10 FULL
3: 100 HALF
4: 100 FULL
7: AUTO
PoE (Power Over Ethernet)
This setting controls the 48VDC PoE supply feature, and is enabled by default.
Field
Description
switch.poe.enabled
0: Disabled
1: Enabled
