Page #36 background imageLoading...
Page #36 background image
NS50 wireless network switch
User Manual
Revision C
Chapter 3: Installation
© 2012 MST Global
Commercial in Confidence
26
Connecting a NS50 to a branch NS50 requires simply connecting composite cables to the additional
fibre ports. The connected fibre ports will cause the corresponding fibre port LEDs to become active.
If you are adding NS50 units to an existing system, please consult your MST System Engineer to
ensure power requirements are being met.
3.7 Standard Composite and Fibre Cable Lengths
While custom cable runs can be made where necessary, it is faster and cheaper to use the following
standard cable lengths supplied by MST:
Table 1: Composite Cable
Part Number
Composite Cable Length
W-CFC-006-T80
80m
W-CFC-006-T125
125m
W-CFC-006-T175
175m
W-CFC-006-T250
250m
W-CFC-006-T325
325m
Table 2: Fibre-Only Cable Cable
Part Number
Composite Cable Length
W-CFC-007-T100
100m
W-CFC-007-T175
175m
W-CFC-007-T325
325m
W-CFC-007-T650
650m
3.8 Connecting Ethernet Cable to the NS50
The external Ethernet ports are located on the underside of the NS50, and are used to connect to
Ethernet devices (such as computers, Ethernet controlled PLCs, hard-wired Ethernet Phones and IP
video devices). An Ethernet cable with a RJ45 connector is used to connect PoE devices. Ethernet
cables are required to meet specifications for use in a mining environment in Ethernet Cable
Specifications on page 108.
The following procedure demonstrates how to connect an Ethernet cable to the NS50.
