NS50 wireless network switch
User Manual
Revision C
Chapter 3: Installation
© 2012 MST Global
Commercial in Confidence
19
3.3.3 Installation in a Stope
An installation scheme for a stope is shown in Figure 11: Installation scheme in a stope.
A panel antenna is clamped to a mounting pole, and is chemically adhered into the mine roof.
The panel antenna is angled down into the stope to provide wide wireless coverage.
A Yagi antenna is installed in the roof providing directional coverage down a straight drive.
Each antenna is connected to a WAC in the NS50. The network switch on a mounting plate is
attached to a rock bolt.
The composite cable supplies power and network connectivity to the switch.
