2.18 Milk Cooler Vent Assembly Installation
Install the milk cooler vent assembly by rotating the vent assembly clockwise and allow the retaining
straps to engage in the retaining lugs. See Figure 14.
IMPORTANT: The vent for the milk cooler must be in place at all times. The vent prevents
contaminates from entering the milk cooler and provides proper air flow to prevent internal damage
resulting from vacuum or pressurization when the milk cooler is washed or emptied. Mueller Model
“O,” “OE,” “OH,” and “OHF” milk coolers are designed for operation at normal atmospheric pressure
only.
Figure 14 - Milk Cooler Vent Assembly
Sentry II with Auto-Dosing Assembly Operating Instructions 15 Effective April 1, 2000
VENT ASSEMBLY
MUST BE OVER MILK
INLET AT ALL TIMES!
EL ENSAMBLAJE
DE VENTEO DEBE
ESTAR SOBRE LA
ENTRADA DE LA
LECHE EN TODO
MOMENTO.
30166
CAUTION
▲
!
CUIDADO
▲
!
