9.6 Sentry II Replacement Parts List, Pump Assembly
Sentry II with Auto-Dosing Assembly Operating Instructions 63 Effective April 1, 2000
ITEM QTY PART NO. DESCRIPTION
1A 1 30455 MOTOR, ELECTRIC, .75 HP, 208-230/50-60/1
1B 1 8823665 MOTOR, ELECTRIC, .75 HP, STAINLESS STEEL, 208-230/50-60/1
1C 1 30456 MOTOR, ELECTRIC, 1.5 HP, 208-230/50-60/1
1D 1 8823666 MOTOR, ELECTRIC, 1.5 HP, STAINLESS STEEL, 208-230/50-60/1
2 1 3909 SEAL, SHAFT
3A 1 31195 IMPELLER, 4.25" OD (.75 HP)
3B 1 8802751 IMPELLER, 5" OD (1.5 HP)
4 1 8823074 VALVE, DRAIN, 24 VAC, COIL
5 1 8823300 COIL, DRAIN, VALVE, 24 VAC
6 1 30419 ADAPTER, OUTLET, NEOPRENE, 2" X 2"
7 1 8823058 SCREEN, DRAIN VALVE
8A 1 8822415 SEAL, RETAINER (.75 HP)
8B 1 8822202 SEAL, RETAINER (1.5 HP)
9A 1 30690 GASKET, PUMP HOUSING, 6.625" OD (.75 HP)
9B 1 30691 GASKET, PUMP HOUSING, 8.125" OD (1.5 HP)
10A 1 8823672 PUMP, SUCTION HOUSING (300- TO 600-GALLON MILK COOLER)
10B 1 8823673 PUMP, SUCTION HOUSING (800- TO 1,600-GALLON MILK COOLER)
10C 1 8823678 PUMP, SUCTION HOUSING (2,000- TO 8,000-GALLON MILK COOLER)
11 1 8823232 CONNECTOR, CONDUIT, .375", 90°
12 1 8820593 WASHER, NEOPRENE
13 1 8822085 NUT, LOCK, CONDUIT, .5", NYLON
14 1 8823233 CONNECTOR, CONDUIT, .375", STRAIGHT
15 2LF 8823337 CONDUIT, FLEX, .375", LIQUID TIGHT
16 1 505263 CORD, GRIP, .25" - .375"
17 1 8823231 ELBOW, RUBBER, 45°, 1" ID X 1.375" OD
18 2 30420 CLAMP HOSE, STAINLESS STEEL
