9.4 Sentry II Replacement Parts List, Dosing and Manifold Box
Sentry II with Auto-Dosing Assembly Operating Instructions 61 Effective April 1, 2000
ITEM PART NO. DESCRIPTION
1A 8823002 BOX ASSEMBLY DOSING, SENTRY II (INCLUDES ITEMS 1-14), STANDARD LABEL
1B 8823365 BOX ASSEMBLY DOSING, SENTRY II (INCLUDES ITEMS 1-14), JAPANESE LABEL
2 8822996 TIMER, 230 VAC, 1-1023 SECONDS, DIP SWITCH SELECTABLE
3 8822997 SWITCH, TOGGLE, SPST, OFF/ON/MOMENTARY
4 8822998 SWITCH, TOGGLE, SPTT, ON/ON/ON
5 31381 WASHER, LOCK, TOGGLE SWITCH
6 31382 RING, LOCK, TOGGLE SWITCH
7 3995 BOOT, RUBBER, TOGGLE SWITCH
8 8822978 TERMINAL STRIP, 8 POLE
9 8822976 GEAR MOTOR, 230-VAC, 50/60-HZ, 58-RPM INTERMITTENT DUTY
10A 8822977 KIT, PERISTALTIC PUMP (INCLUDES HOUSING, COVER, ROLLER BRACKET, & .25" NORPRENE HOSE)
10B 8823710 .25" X 9" NORPRENE HOSE
11 8823011 SPACER, .375" OD X 1.5" LG. X .171" ID, NYLON
12 3200128 SCREW, MACHINE, .25-20NC X 1", 18-8 S/S
13 8822974 SCREW, MACHINE, 8-32 NC X 2.25", 18-8 S/S
14 8823030 TERMINAL BLOCK INSULATOR
15 8823021 ADAPTER, BARBED MALE
16 8823019 ELBOW, POLYPROPYLENE, 90 DEGREE X .25" BARB X .25" BARB
17 8823041 TUBE, .375" OD X .25" ID (CLEAR PVC)
18 8823042 TUBE, .375" OD X .25" ID (BLUE PVC)
19 8823043 TUBE, .375" OD X .25" ID (RED PVC)
20 8823068 HOSE CLAMP, PLASTIC, RYAN
21 8823236 BOX ASSEMBLY, MANIFOLD SOLUTION (INCLUDES ITEMS 22 - 33)
22 8823071 VALVE, SOLENOID, DUAL, 24-VAC
23 505263 CORD GRIP
24 3690 NUT LOCK CONDUIT
25 8823239 MANIFOLD, SOLUTION
26 8823614 SWITCH, PRESSURE, 5 PSI
27 8823602 ADAPTER HOSE, .5" MPT X .5" HOSE BARB
28 8823240 VALVE, CHECK, .25" MPT X .25" FPT
29 8823709 REDUCER, .25-18 NPT TO .25 UNF
30 8823241 COUPLING, QUICK CONNECT, BODY, .5" NPT
31 8823244 ADAPTER, THREADED, FEMALE
32 8823070 HOSE, .5" ID
33 30423 CLAMP, HOSE, S/S
34 30581 HOSE, .375" ID
35 93590 HOSE ASSEMBLY, WATER (INCLUDES HOT AND COLD HOSE, AND BACK FLOW PREVENTER)
36 8823243 COUPLING, QUICK CONNECT, INSERT, BARBED
37 8823301 COIL, SOLENOID, 24 VAC (REPLACEMENT ONLY)
