9.2 Sentry II Replacement Parts List, Main Control
Sentry II with Auto-Dosing Assembly Operating Instructions 59 Effective April 1, 2000
ITEM PART NO. DESCRIPTION
1 8822971 TRANSFORMER, 240/24 VAC, 75 VA (SEE ITEM 2 FOR 195 VAC)
2 8823060 TRANSFORMER, 195/24 VAC, 150 VA
3 8823007 RELAY, DPST, 240 VAC COIL, 30 AMP, NO
4 8822995 TEMPERATURE CONTROLLER, THERMOCOUPLE INPUT, 2 RELAY OUTPUT
5 8822988 INDICATOR LIGHT, 24 VAC, RED
6 8822989 PUSH-BUTTON SWITCH, LIGHTED, 24 VAC, GREEN
7 8822990 PUSH-BUTTON SWITCH, LIGHTED, 24 VAC, AMBER
8 8822991 PUSH-BUTTON SWITCH, LIGHTED, 24 VAC, BLUE
9 8822992 RELAY, 4PDT, 24 VAC, 14 PIN
10 8822993 RELAY, SOCKET, 14 PIN
11A 8823313 PROGRAMMABLE CONTROLLER, PLC, FACTORY PROGRAMMED (US)
11B 8823314 PROGRAMMABLE CONTROLLER, PLC, FACTORY PROGRAMMED (JAPAN)
12 8822985 TERMINAL STRIP, FUSED
13 8822983 FUSE CARTRIDGE, 1 AMP, 250V BUSS MDL-1
14 8822984 FUSE CARTRIDGE, 2 AMP, 250V BUSS MDL-2
15 8820704 FUSE CARTRIDGE, 3 AMP, 250V BUSS AGC-3
16 8800086 TOGGLE SWITCH, DPST, 10 AMP
17 8822981 SELECTOR SWITCH, 3 POSITION ROTARY
18 8823011 SPACER, .375" OD X 1.50" LG, NYLON
19 8822927 TERMINAL BLOCK, INSULATOR
20 8808268 REPLACEMENT BULB, 24 VAC
21 8820165 THERMOCOUPLE, 50 FEET
22 8822013 CABLE, PLC TO MTA HAND-HELD INTERFACE PROGRAMMER
23 8822179 MTA, HAND-HELD INTERFACE PROGRAMMER WITH CABLE (U.S. PROGRAM)
24 8823315 MTA, HAND-HELD INTERFACE PROGRAMMER WITH CABLE (JAPAN PROGRAM)
25 8820166 THERMOCOUPLE EXTENSION WIRE, 20/2 TYPE “T” (PURCHASED BY THE FOOT)
26 8822361 NUT, WIRE, ALL PLASTIC FOR THERMOCOUPLE CONNECTIONS
