8.2 Metric Weights and Conversions
Dimensions not to be used for construction unless certified.
1
Actual calibration capacity may exceed certified capacity
2
Minimum and maximum clearance under the milk cooler with standard adjustable legs.
3
Approximate weight measured in kilograms (includes agitator(s), pump assembly, and controls).
Sentry II with Auto-Dosing Assembly Operating Instructions 57 Effective April 1, 2000
Capacity
1
ABCDE FGH
2
J No. of Weight
3
Model (liters) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) Legs (Empty)
O-500 1,893 1981.2 1549.4 946.2 1295.4 1619.3 457.2 1066.8 101-127 209.6 4 424
O-600 2,271 2286.0 1549.4 946.2 1301.8 1625.6 457.2 1371.6 101-127 209.6 4 474
O-800S 3,028 2032.0 1809.8 1270.0 1543.1 1866.9 457.2 1117.6 101-203 209.6 4 582
O-1000S 3,785 2590.8 1809.8 1270.0 1555.8 1879.6 457.2 838.2 101-203 209.6 6 694
O-1000D 3,785 2590.8 1809.8 1270.0 1555.8 1879.6 457.2 838.2 101-203 209.6 6 715
O-1350 5,110 2590.8 2032.0 1225.6 1755.8 2082.8 457.2 838.2 178-229 209.6 6 803
O-1600 6,057 3048.0 2032.0 1225.6 1765.3 2089.2 457.2 1066.8 178-229 209.6 6 902
O-2000 7,571 3937.0 2032.0 1225.6 1765.3 2108.2 444.5 1016.0 178-229 209.6 8 1,103
O-2700 10,221 3937.0 2298.7 1397.0 2006.6 2333.6 444.5 1016.0 178-229 209.6 8 1,461
O-3000 11,356 4470.4 2298.7 1397.0 2016.1 2343.2 457.2 889.0 178-229 209.6 10 1,720
O-4000 15,142 4978.4 2479.7 1473.2 2190.8 2514.6 457.2 812.8 178-229 209.6 12 2,713
O-5000 18,927 4978.4 2743.2 1574.8 2371.7 2698.8 457.2 812.8 178-229 136.5 12 2,849
O-6000 22,712 4978.4 3022.6 1828.8 2524.1 2851.2 311.2 622.3 178-229 136.5 16 3,081
O-7000 26,498 4978.4 3225.8 1981.2 2705.1 3029.0 311.2 622.3 178-229 136.5 16 3,135
O-8000 30,283 5791.2 3208.3 1981.2 2721.0 3029.0 304.8 647.7 178-229 136.5 18 3513
