Multicomp-Pro
"Communications" menu item. Set "Connect using" to LAN. Set IP and Port to
the same value in the oscilloscope in the step (4). If you can get data normally,
the connection is successful.
Figure 5-8 Set the network parameters of the Oscilloscope Software
Connect with PC as Wi-Fi Station
The oscilloscope and PC should be on the same network (LAN).
(1) In the oscilloscope, click the icon, click Utility. Select Function in the
bottom menu. Select LAN Set in the left menu. In the bottom menu, set the
Type item as WIFI-STA, and select Set in the bottom menu.
(2) In the right menu, select SSID, a keyboard will pop up. Touch the keyboard to
input the name of the Wi-Fi hotspot.
(3) In the right menu, select Encryption, push to set the Encryption type of the
Wi-Fi hotspot. Open type needs no password. WEP or WPA type need to input
the password. In the right menu, select Password, use the keyboard to input
the Wi-Fi hotspot password.
(4) In the right menu, select IP:PORT, click or to set the PORT. Here, we
set it to 3000.
(5) After setting, select ON in the Status menu. The value of IP is displayed in
IP:PORT menu. Here IP is 10.1.1.126. A changing icon
appears on the
top right of the screen.
