multicomp pro MP Series User Manual

Multicomp-Pro
72
Measure Automatically
Click to call up the menu panel. Click the Measure softkey on panel to
display the Measure menu. At most 8 types of measurements could be
displayed on the bottom left of the screen.
The oscilloscopes provide 39 parameters for auto measurement, including
Period, Frequency, Mean, PK-PK, RMS, Max, Min, Top, Base, Amplitude,
Overshoot, Preshoot, Rise Time, Fall Time, +PulseWidth, -PulseWidth,
+Duty Cycle, -Duty Cycle, Screen Duty, FRR, FRF, FFR, FFF, LRR, LRF,
LFR, LFF, Delay A→B , Delay A→B , Cycle RMS, Cursor RMS, FRR,
FRF, FFR, FFF, LRR, LRF, LFR, LFF, Phase A→B , Phase A→B ,
+PulseCount, -PulseCount, RiseEdgeCnt, FallEdgeCnt, Area, and Cycle
Area.
The "Automatic Measurements" menu is described as the following table:
Function Menu
Description
Add
Meas Type
(left menu)
Select the measure types
Source
CH1 CH2
CH3 CH4
Select the source
Add
Add the selected measure types
(shown at the left bottom, you could
only add 8 types at most)
Remove
Meas Type
(left menu)
Select the types need to be deleted.
The selected type and source are
shown in the Remove menu on the
right.
Remove
Remove the selected measure type
Remove All
Remove all the measures
Snapshot
ON
OFF
Show all the measures of the
snapshot source
Turn off the snapshot
Source
CH1
CH2
CH3
CH4
Select the snapshot source
Set
Gating
Screen
Cursor
Select "Screen" or "Cursor" to set the
cursor range
Statistics
ON
OFF
select "ON" or "OFF" for measuremen
t value statistics
