Multicomp-Pro
6. Communication with Android Device
via Wi-Fi (Optional)
The oscilloscope supports communications with Android based smart device via
Wi-Fi. You can use the free application software on the Android based smart
devices to view the waveform synchronously, perform remote control, the
waveform can be saved as image (BMP, PNG) or file (CSV, BIN), or shared via
installed sharing apps.
System Requirements of Mobile Devices
Android Versions: 4.0 and above
How to Connect
In Wi-Fi settings of the oscilloscope, there are two connection types. One is
WIFI-AP (Access Point), the oscilloscope is set as Wi-Fi access point, the Android
device can be connected to it directly. The other type is WIFI-STA (Station), the
oscilloscope is set as Wi-Fi station. The Android device can be connected to it
through a Wi-Fi hotspot.
Connect with APP as Wi-Fi Access Point
(1) In the oscilloscope, click the icon, click Utility. Select Function in the
bottom menu. Select LAN Set in the left menu. In the bottom menu, set the
Type item as WIFI-AP, and select Set in the bottom menu.
(2) In the right menu, select SSID, a keyboard will pop up. You can touch the
keyboard to set the access point name.
(3) In the right menu, select Encryption, push again to set the type. Open type
needs no password. WEP or WPA type need to set the password. You can
select WPA. In the right menu, select Password, use the keyboard to set the
Wi-Fi password (8 to 32 characters).
(4) In the right menu, select IP:PORT, IP is fixed by the oscilloscope, and cannot
be edited. Click or to set the PORT.
(5) After setting, select ON in the Status menu. The icon appears on the top
right of the screen.
