Multicomp-Pro
Touchscreen Controls
You can control the oscilloscope by different gestures. The touchable icon at the
top right of the screen is used to enable (
) or disable (
) the touchscreen
controls.
The instruction of touchscreen controls is as below.
Run/Stop: Click the or on the left top of the display area to run or stop
the waveform sampling.
Force trigger: Click the on the left top of the display area to force a
trigger signal, which is mainly applied to the "Normal" and "Single" trigger
modes.
Autoset: Click the on the left top of the display area to auto set.
Select a menu item: Touch the menu items in the bottom menu, or in the right
menu, or in the left menu.
Switch menu items: If there are options that can be switched on the menu,
you can repeatedly touch the area of the menu item to switch, or push the
corresponding button to switch. See figure below:
Press repeatedly to
switch the options
Adjust value on the menu item:
Click to increase the
value of cursor position
Move the cursor
Click to decrease the
value of cursor position
Scroll the list: If there is a scroll bar in the left menu, you can swipe up and
down to scroll the list.
Touchable menu panel: Click the
icon on the right bottom of the display
area, a menu will be shown. Click to enter the corresponding function menu.
To Next Page
