9. Technical Specifications
Unless otherwise specified, the technical specifications applied are for MP
four-channel series only, and Probes attenuation set as 10X. Only if the
oscilloscope fulfills the following two conditions at first, these specification
standards can be reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on
P13).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Oscilloscope
Performance Characteristics
Instruction
Bandwidth
MP720775
70 MHz
MP720645
MP720776
100 MHz
Vertical Resolution (A/D)
MP720775
8 bits
MP720645
8 bits
MP720776
8 bits/12 bits/14 bits
Channel
4
Waveform Capture Rate
45,000 wfms/s
Multi-level Gray Scale Display &
Color Temperature Display
(Use gray scale to indicate frequency of
occurrence, where frequently occurring
waveform are bright.)
Support
Magnifier Function
(The magnifier window can display the
magnified wave of the wave selection
horizontally and vertically.)
MP720775
MP720645
Not support
MP720775
A
MP720776
Support
Acquisition
Mode
Normal, Peak detect, Averaging
Sample rate
(real time)
MP720775
MP720645
Four CH
250 MSa/s
Dual CH*
500 MSa/s
Single CH
1 GSa/s
MP720776
8 bits
mode
Four CH
250 MSa/s
Dual CH*
500 MSa/s
Single CH
1 GSa/s
12 bits
mode
Four CH
125 MSa/s
Dual CH*
250 MSa/s
