multicomp pro MP Series User Manual

Multicomp-Pro
125
Performance Characteristics
Instruction
Automatic
Period, Frequency, Mean, PK-PK, RMS,
Max, Min, Top, Base, Amplitude, Overshoot,
Preshoot, Rise Time, Fall Time, +Pulse
Width, -Pulse Width, +Duty Cycle, -Duty
Cycle, Delay A→B , Delay A→B , Cycle
RMS, Cursor RMS, Screen Duty, FRR, FRF,
FFR, FFF, LRR, LRF, LFR, LFF, Phase
A→B , Phase A→B , +Pulse Count,
-Pulse Count, Rise Edge Count, Fall Edge
Count, Area, and Cycle Area.
Waveform Math
＋, －, *, / ,FFT, FFTrms, Intg, Diff, Sqrt,
User Defined Function, digital filter (low
pass, high pass, band pass, band reject)
Decoding Type
UART, I
2
C, SPI, CAN
Waveform storage
100 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
USB Host, USB Device; Trig Out(Pass/Fail); LAN port
Printer
Compatibility
PictBridge
Counter
Support
* For MP720775(A), Max Sample rate (real time) for Dual CH should meet either
following condition:
 CH1&CH2 on, CH3&CH4 off;
 CH1&CH2 off, CH3&CH4 on.
* For MP720645(A), Max Sample rate (real time) for Dual CH should meet the following
condition:
CH1 and CH2 can not be turned on simultaneously, CH3 and CH4 can not be turned
on simultaneously.
 CH1&CH3 on, the others off;
 CH1&CH4 on, the others off;
 CH2&CH3 on, the others off;
 CH2&CH4 on, the others off.
Trigger
Performance Characteristics
Instruction
Trigger level range
Internal
±5 div from the screen center
Trigger level
Accuracy (typical)
Internal
±0.3 div
Trigger
displacement
According to Record length and time base
