multicomp pro MP Series User Manual

Multicomp-Pro
126
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger
slope
Rising, Falling
Video Trigger
Modulation
Support standard NTSC, PAL and SECAM
broadcast systems
Line number range
1-525 (NTSC) and 1-625 (PAL/SECAM)
Pulse trigger
Trigger condition
Positive pulse：＞, ＜, ＝
Negative pulse：＞, ＜, ＝
Pulse Width range
30 ns to 10 s
Slope Trigger
Trigger condition
Positive pulse：＞, ＜, ＝
Negative pulse：＞, ＜, ＝
Time setting
30 ns to 10 s
Runt Trigger
Polarity
Positive, Negative
Pulse Width
Condition
>, =, <
Pulse Width Range
30 ns to 10 s
Windows Trigger
Polarity
Positive, Negative
Trigger Position
Enter, Exit, Time
Windows Time
30 ns to 10 s
Timeout Trigger
Edge Type
Rising, Falling
Idle Time
30 ns to 10 s
Nth Edge Trigger
Edge Type
Rising, Falling
Idle Time
30 ns to 10 s
Edge Number
1 to 128
Logic Trigger
Logic Mode
AND, OR, XNOR, XOR
Input Mode
H, L, X, Rising, Falling
Output Mode
Goes True, Goes False, Is True >,
Is True <, Is True =
UART Trigger
Polarity
Normal, Inverted
Trigger Condition
Start, Error, Check Error, Data
Baud Rate
Common, Custom
Data Bits
5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition
Start, Restart, Stop, ACK Lost, Address,
Data, Addr/Data
Address Bits
7 bit, 8 bit, 10 bit
Address Range
0 to 127, 0 to 255, 0 to 1023
Byte Length
1 to 5
SPI Trigger
Trigger Condition
Timeout
