Multicomp-Pro
124
Performance Characteristics
Instruction
Sampling rate / relay
time accuracy
±10 ppm max (Ta = +25)
Interval(T) accuracy
(DC - 100MHz)
Single
±(1 interval time+1 ppm×reading+0.6 ns);
Average>16
±(1 interval time +1 ppm×reading+0.4 ns)
Vertical system
Sensitivity
1 mV/div - 10 V/div
Displacement
±2 V (1 mV/div 50 mV/div)
±20 V (100 mV/div 1 V/div)
±200 V (2 V/div 10 V/div)
Analog bandwidth
MP720775
70 MHz
MP720645
MP720776
100 MHz
Single bandwidth
MP720775
DC to 70 MHz
MP720645
MP720776
DC to 100 MHz
Low Frequency
≥10 Hz (at input, AC coupling, -3 dB)
Rise time (at input,
Typical)
MP720775
≤ 5.0 ns
MP720645
MP720776
≤ 3.5 ns
DC gain accuracy
MP720775
MP720645
1 mV
±4%
≥2 mV
±3%
MP720776
8 bits mode
1 mV
±4%
≥2 mV
±3%
12 bits mode
14 bits mode
1 mV
±3%
≥2 mV
±2%
DC accuracy (average)
Delta Volts between any two averages of
≥16 waveforms acquired with the same
scope setup and ambient conditions (V):
±(3% rdg + 0.05 div)
Waveform inverted ON/OFF
Measurement
Cursor
V, T, T&V between cursors,
auto cursor
