Fax Functions
Preparations
Connect the line cable
1
Loop the telephone line cable and attach the ferrite core supplied with the ma-
chine as illustration below. The telephone line cable loop should be about 5 cm
from the end.
Ferrite core
2
Connect the telephone line cable (ferrite core side) to the jack marked “ ”.
Connect the other end of the telephone line cable to the telephone wall jack.
