Muratec MFX-1820 - Transporting the Machine

8
Platen cover
881 mm
321 mm
925 mm
296 mm
100 mm
100 mm100 mm
90°
1166 mm
100 mm
879 mm
96 mm 91 mm
Transporting the machine
•Beforetransportingthemachine,besuretocheckthatyoudisconnecttheplugfromtheoutletandremovethe
line cable. Use at least two people to move the machine.
•Whentransportingthemachine,removethetonercartridge.
•Whentransportingthemachine,supportthepartsshowninthegurebelow.Whenyouliftthemachine,be
sure to bend your knees sufficiently so as not to damage your back.
