Myron L 750 II Series User Manual

47
For Conductivity/TDS - X1, X10 and X100.
For Resistivity - X1, 0.1, and 0.01.
If adding an alarm/control range.
1. Locate the 8 position select switch on the 3SR Module.
2. Set appropriate select switch UP or ON, i.e. to add
X100, set switch marked X100 UP or ON, see
  gureIII.H.7.
If changing alarm/control from one range to another, i.e. X1 to
X10 Range.
1. Locate the 8 position select switch on the 3SR Module.
2. Set the X1 select switch in the DOWN or OFF position.
3. Set the X10 select switch in the UP or ON position, see
  gureIII.H.8.
To disable either COND/TDS or Resistivity alarm/control
function completely.
1. Locate the 8 position select switch on the 3SR Module.
2. Set all XprexedandSprexedselectswitchesinthe
  DOWNorOFFposition,seegureIII.H.9.
TorecongureConductivitytoResistivityorviseversa.
If you have a Resistivity Monitor/controller and ordered a 3SRO
Moduleasanaccessoryyoumayneedtoreconguretheselect
switch for it to Range properly.
1. Locate the 8 position select switch on the 3SR Module.
2. Set the COND select switch in the DOWN or
  OFFposition,seegureIII.H.10.
3. Set the RES select switch in the UP or ON position,
  seegureIII.H.10.
Naturally,ifyouhavea3SRModuleconguredforaResistivity
Monitor/controller and desire it to be for a Conductivity Monitor/
controller, reverse #2 & 3 above.
REASSEMBLY:
 1. Carefullyreinstallthefrontpanel,bottomrst.Ensure
no wires have been pinched between enclosure and
front panel.
2. Reinstall the four (4) screws and tighten.
3. To operate, turn power ON.
Figure III.H.6 Figure III.H.8Figure III.H.7
Figure III.H.9
Factory Default
ONON ON
COND RES X1 X10 X100 S1 S2 S3 COND RES X1 X10 X100 S1 S2 S3 COND RES X1 X10 X100 S1 S2 S3 COND RES X1 X10 X100 S1 S2 S3
ON
COND RES X1 X10 X100 S1 S2 S3
Figure III.H.10
ON
