8.2.2 Cancel Passcode or Reset to Default
Passcode
Stroke Learning
Yes No
Short
Push
Reset to Default Set
LEVEL 2
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
00
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
000
Rotate
Dial
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
004
Short
Push
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
0044
Rotate
Dial
0045
Short
Push
Correct PassCode!
If you don’t know
the password,
Keep Pushing Switch,
Return to Normal mode
0045
Reset to Default Set
If you don’t know
the passcode,
Keep Pushing Switch,
Return to Normal mode
DN 1712
Figure 8 
8.2.3 Stroke Learning
Stroke Learning is used to measure from Fully Closed to Fully Open points in eort to determine where Check Points should happen.
Stroke Learning is also used to determine if an exisng Operator Type is correct, and/or to determine if Handing is correct.
1. Briey press down on the Rotary Dial to select:
X Yes
• 
• 
X No
• 

• 

screens.
SECTION 8.3: Level Three and Four: Seng Category and Menu Items
Short
Push
DN 1716
Passcode
Stroke Learning
Yes No
Go to Se ng menu
Se ng Category
Base Se ng
Movement Se ng
Op onal Se ng
Output Se ng
Input Se ng
History Data
LEVEL 3
Low Energy or Full
Low Full
Rotate
Dial
LEVEL 4
LEVEL 2
Long Push
Long Push
Figure 9 
