19 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 11.2: Switches and Sensors with Monitoring
DN 1895
5
1
BROWN (power +)
RED (power-)
2
34 67
BLACK (signal common)
Acusensor M Harness
P.N. A-01292
GREY (test +)
GREEN (signal N.O.)
YELLOW (test-)
GREY AND YELLOW NOT
NEEDED ON THIS SENSOR
Approach Side Ac va on/Safety
Acusensor M
P.N. V-00741
To Terminal # on Opus Control
Fold Side Ac va on
Acusensor M
P.N. V-00741
GREY AND YELLOW NOT NEEDED
ON THIS SENSOR
YELLOW
GREEN
GREY
BROWN
RED
BLACK
Fold Side Safety
Acusensor M
P.N. V-00741
Acusensor M Harness
P.N. A-01292
YELLOW
GREEN
GREY
BROWN
RED
BLACK
2
1
2
4
1
2
2
2
6
7
8BABreakout Used mainly for sliding doors, can be used for ON/OFF with swing doors.
9SQ Sequen al Sequen al Ac va on signals to open, or signals to close.
10 H Input HProgrammable input
11 M0 Mode 0 When grounded, puts door into One-Way Mode (Hold-Open when grounded with M1)
12 M1 Mode 1 When grounded, puts door into Night Mode (Hold Open when grounded with M0)
13 Out2 Auxillary Output 2Programmable output, closes to GND
14 GND Ground Ground (common) for all above signals
BLUE to pin 8
BLACK to pin 11 on Opus
WHITE to pin 12
RED to pin 14
5
4
3
2
1
EXIT
AUTO
ON
OFF
HOLD OPEN
1413121110
98
N.O. Breakout Switches
Rocker Switch
A-01048
1 12VDC +12VDC
2 GND Common for 12V and Signals
361Interior Ac va on
462Exterior Ac va on/Programmable Input
56BSwing Door Con nuous Safetly (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
(may be used with sensors equipped with monitor input)
2
1
3
2
BLACK
BLUE
WHITE
RED
To Next Page
