Input Setting
Parameter Terminal Default Range Description
Input H
Open Timer
N/A Same as
Open Timer
Same as Open Timer,
0 thru 10, 12,15, 20,25 sec
Open Timer Seng for this Terminal only
Input 61
Circuit
N/A


► 
► 
Circuit logic for Input 61
Input 62
Circuit
N/A


► 
► 
Circuit logic for Input 62
Input 6B
Circuit
N/A


► 
► 
Circuit logic for Input 6B
Input
SWL Circuit
N/A


► 
► 
Circuit logic for Input SWL
Input BA
Circuit
N/A


► 
► 
Circuit logic for Input BA
6B Stop
Closing
N/A
No ► Yes
Determines door movement stop or close, when 6B is ON
at latch check while closing cycle.
► No
After 6B
Open?
N/A
Yes ► Yes
Determines door movement open or close, aer 6B.
► No
61
Monitoring
N/A
 ► 
► 
Sensor monitoring function *
62
Monitoring
N/A
 ► 
► 
Sensor monitoring function *
6B
Monitoring
N/A
 ► 
► 
Sensor monitoring function *
SWL
Monitoring
N/A
 ► 
► 
Sensor monitoring function *
* If Monitoring is enabled for any input then the sensor MUST be connected to Output 1 or 2.
Output 1 or 2 must then be programmed to “Sensor Health Check”. If an error occurs, the door will hold open until the error clears
or the power is cycled. Monitoring is controlled by the U30 Microprocessor Control for SLIDE doors only.
SECTION 9.6: History Seng
History Data
Parameter Description
Operation Cnt
► 
► 
Open Recycle Cnt Indicates number of mes the Door reversed direcon during Opening cycle aer sensing:
► 
► 
Close Recycle Cnt Indicates number of mes the Door reversed direcon during Closing cycle aer sensing:
► 
► 
Latest Recycle Position
► 
► 

SECTION 9.7: Test Open
<= Test Open =>
Tests Open/Close door cycle while ignoring Safety Signals.
